WELL MAINTAINED RO RO VESSEL FOR SALE

‘CIMBRIA SEAWAYS’ EX ‘AQUAE’ RORO
-  FLAG UK
– GT 12,189
– NT 3,656
– LOA 145M -
 BEAM 20.40M – ACCOM FOR PAX 12 – DECKS 4 – TEU 445 – 2,026LM
ABOUT 6,897 TDW ON 6.62M DRAFT
Built: 1986 by Frederikshavn Vaerft, Denmark
Classification: DNV 1A1, General Cargo Carrier RO/RO CONTAINER E0
S.S. PASSED JUNE 2010 - D.D. DONE APRIL 2010
Propelling machinery:
M. E. 1 x MAK 6M 601 9000 BHP at 428 rpm through gear 407/115 Coupled
    to 1 x CP propeller
1 x bow thruster at 1350kW, 2 x stern thrusters at 660 kW each
Tank top, main deck, upper tween deck and weather deck
All vehicle decks free height from 4.40m to 4.50m
Speed and consumption figures:
Abt 16,4 knots at abt 24,8 MTS (IFO 180) per day, shaft generator
disconnected.
MDO abt 2,2 MT per day, shaft generator connected.
Shaft generator: 2375kVA -440V- 3116A- 1800RPM- 60Hz.
Auxiliary machinery:
2 x MAK 6M 332 at 1632 BHP/900 rpm each coupled to a 1415 kVA
generator
Stabilizers:
Simplex-Compact - Fin Stabilizers
Type SK40
Area of each fin, 8m2
Time for retraction and extension - 120s
Voltage:
3 x 440 Volts at 60 Hz
Shore connection capacity 160 Amp.
Hoistable ramp:
Maker: Mac Gregor Navire  Newbuild Nr 417  Order Nr: 201 203 300
Type: Hoistable Ramp  Wire / Hydraulic
Length : 44.0 Mtr
Width :  3,6 Mtr
Capacity:  2,8 Ton per lane meter , Tot 120 Tonnes
Stern ramp:
Maker: Mac Gregor Navire  Newbuild Nr 417  Order Nr 201 203 300
Type: 2 pcs Stern Ramp / Door Water tight in closed position
Operation by Hydraulic Jigger winch Total length Incl Flap: Each Ramp
14.5  Mtr Length of  Flap : Each Ramp 2.0 Mtr Breadth Of Drive Way:
Each Ramp 6.5 Mtr Total Breadth of Ramp: 7.1 MtrStb Ramp 7.3 Port
Side Ramp The Clear Opening for each ramp in the stern transom is:
H  4.9 Mtr  X B 6.5 Mtr.
Design Load: Heavy Load Wagon total weight 100 Tonnes. One fork lift
truck with an axle load of 35 tonnes on four wheels , wheel print
according DNV rules, tyre pressure 800 kN/m2 One roll trailer 40 feet
- 40 tonnes with an axle load of 34 tonnes on 16 solid rubber tyres
The ramps are designed as water tight doors
ACCOMMODATION FOR 12 DRIVERS.
(DTLS WOG)
UNDERSTAND VESSEL IN VERY GOOD `condition` CONSIDERING HER AGE.

VESSEL PRESENTLY TRADING IN WESTERN MEDITERRANEAN BETWEEN

MARSEILLES AND TUNIS AND EASILY INSPECTABLE MARSEILLES.
