REF366/REEFER/1989-1/5580CBM/ USD 4.80 MILLION

REF366/REEFER/1989-1/5580CBM/ USD 4.80 MILLION
4,800,000.00
Title
REF366/REEFER/1989-1/5580CBM/ USD 4.80 MILLION
Ref No
RF259955
Built
1989
DWT
5,053
LDT
2,828
Flag
PANAMA
Model
REEFER
Additional information
Description
NAME REF366
TYPE DEEP FREEZER/SASHIMI CARRIER
FLAG PANAMA
PORT OF REGISTRY PANAMA
BUILT built_in 1989-1
BUILT PLACE FUKUOKA SHIPBUILDING Co, JAPAN
CLASS NK MNS RMC (CLASS SEEMS WITHDRAWN ON 2013-04 WHEN SURVEY ON 2015-01 OR 2013-11)
SS 2015-10
DD 2015-08
LOA 117.40M
LBP 107.0M
BEAM 16.42M
DEPTH 9.95M
DRAFT SUMMER: 7.114 M
GT INTERNATIONAL: 4579 MT
PANAMA: 5090MT
SUEZ: 4767MT
NT INTERNATIONAL: 2156MT
PANAMA: 3593 MT
SUEZ: 3767 MT
DWT 5053MT
LDT 2828MT
FLOOR SPACE CAPACITY 2184SQM
GEAR DERRICKS 8×5MT / UP 4×3MT, 6M OUTREACH
ME MITSUBISHI 8UEC37LA 5600 BHP×210 RPM MAX, 5040 BHP×203 RPM SERVICE SPEED
AE/GENERATOR A/E: 2×DAIHATSU 6DLB-22 900 PS×720RPM
GEN: 763 KVA
PROPELLER 4 SOLID KEYLESS BLADES
SPEED/CONSUMPTION ME CONSUMPTION:
DEEP LADEN 15.50 ON 15(380)
BAL/BAN 16.5 ON 15MT
(NOTE: IFO380CST RMG-380)
D/G CONSUMPTION:
PORT-REEFER PLANT OFF: ABT. 1.6MT./DAY(IFO380CST RMG-380)
PORT-REEFER PLANT ON: ABT 3MT/DAY (IFO380CST RMG-380)
FUEL TYPE IFO380
HOLD NUMBER 4
HATCH NUMBER 4
HATCH SIZE 5.50×5.00
COMPARTMENT 11
Hold No.1:     A,B
Hold No.2-4:   A,B,C
DECKS 3
DECK AREA 2184SQM
DECK HEIGHT MIN 2.20M
CAPACITY (CBFT) 197056
CAPACITY (CBM) 5580
TANKS CAPACITY FUEL: 728.26 MT;
GO: 359 MT;
FRESH WATER: 240 MT
REEFER PLANT R-22 DIRECT EXPANSION
COOLING SECTIONS 8
GRATINGS WOODEN- MAX LOAD 5MT
(CARGO + FORKLIFT WITH 4 PNEUMATIC TYRES)
TYPE OF THE VENT SYSTEM
VENT VERTICAL FRESH AIR SUPPLY-3.4 TIME/H;
RECIRCULATION AIR 90-60 T/H
SIDE SHORING YES
TEMPERATURE -55/+15℃ IN HO.2-4 NO.1 -32/+15℃
INSPECTION PLACE CHINA
DELIVERY PLACE CHINA
PRICE USD 4.80 MILLION
REMARK VESSEL IS DRYDOCKING IN COSCO CHINA, REACTIVATED AND REPAIRED, OWNER IS INDUCED TO SELL IT.
ALL SPEEDS/CONSUMPTIONS BASIS CALM SEAS/MAX BEAUFORT 2.
VSL IS BURNING MDO WHEN NAVIGATING AND/OR MENOEUVERING AT REDUCED RPM, IN NARROW/SWALLOW/RESTRICTED WATERS (E.G. ENTERING/LEAVING PORT, TRANSITING CANALS AND SHIFTINGS AT T/S ANCHORAGES ETC.)
FUEL GRADES TO BE IN ACCORDANCE WITH ISO8217:2005(E) AND TO BE SUPPLIED IN ACCORDANCE WITH MARPOL 73/78 ANNEX VI REQUIREMENTS (AND SUBSEQUENT AMENDMENTS).
VESSEL IS EQUIPPED WITH OCEAN FENDERS FOR HIGH SEA TRANSSHIPMENT
