REF718/ REEFER/ 1992/ 12020 CBM/ USD 4.35 MILLION

REF718/ REEFER/ 1992/ 12020 CBM/ USD 4.35 MILLION
4,350,000.00
Hakkında
REF718/ REEFER/ 1992/ 12020 CBM/ USD 4.35 MILLION
Reference Number
RF694871
Yıl
1992
DWT
11,054
LDT
4,935.7000
Flag
BAHAMAS
Model
REEFER
Ek Bilgiler
İlan Detayları
NAME REF718
TYPE REEFER
FLAG BAHAMAS
PORT OF REGISTRY
BUILT built_in 1992
BUILT PLACE KVAERNER KLEVEN, NORWAY
CLASS BV
NAVIGATION AREA
SS
DD
LOA 140.50 M
LBP
BEAM 19.70 M
DEPTH 13.00 M
DRAFT 9.62 M
GT 7944 MT (INTERNATIONAL)
8528 MT (PANAMA)
8469 MT (SUEZ)
NT 4632 MT (INTERNATIONAL)
6509 MT (PANAMA)
6774 MT (SUEZ)
DWT 11054 MT (SUMMER)
LDT 4935.7 MT
DISPLACEMENT
GEAR CRANES:
2 x 8MT, 20M FROM CL (OUT-REACH 10.15M)
2 x 36MT, 22M FROM CL (OUT-REACH 12.15M)
OR
2 x 21MT, 22.5M FROM CL (OUT-REACH 12.65M)
ME MAN 2 S.A., 9-CYL., 16212 HP
AE/GENERATOR
COOLING SYSTEM
SPEED/CONSUMPTION BALLAST:
MAX 19.5 KONTS ON ABOUT 37 MT IFO380 CST
18 KONTS ON ABOUT 31 MT IFO380 CST
ECO SPEED ABOUT 16.5 KONTS ON ABOUT 27 MT IFO380 CST

FRUIT LADEN UNDER DECK NO CONTAINERS:
MAX: ABOUT 19 KONTS ON ABOUT 43 MT IFO380 CST
18 KONTS ON ABOUT 37 MT IFO380 CST
ECO SPEED ABOUT 16 KONTS ON ABOUT 29 MT IFO380 CST

FRUIT LADEN UNDER DECK FULL REEFER CONTAINERS ON DECK:
MAX 19 KONTS ON ABOUT 45.5 MT IFO380 CST+1.8 MT MGO
18 KONTS ON ABOUT 39 MT IFO380 CST +1.8 MT MGO
ECO SPEED ABOUT 16 KONTS ON ABOUT 32 MT IFO380 CST +1.8 MT MGO

AT PORT BOILER 1.5 MT IFO RMG 380
AT PORT IDLE 1.8 MT MGO DMA
AT PORT WORKING 5.2 MT MGO DMA
FUEL TYPE
TANKS CAPACITY
HOLD NUMBER 4
HATCH NUMBER 4
HATCH SIZE 12.6 x 5.4; 12.6 x 10.6
COMPARTMENT 15
DECKS
DECK AREA
DECK HEIGHT
CAPACITY (CBFT) 424307
CAPACITY (CBM) 12020
FLOOR SPACE CAPACITY(SQM) 4776
GRATING ALU, 7.0 MT CARGO AND FORKLIFT WITH PNUEMATIC TIRES
TEMPERATURE ZONE 1A/BC, 2A/BCD, 3 A/BCD, 4 A/BCD
TEMPERATURE -29 / +15 DC
VENT/TYPE OF THE VENT SYSTEM 90/HR, VERTICAL
AIR CHANGE 4/HR
PALLETS
CONTAINER CAPCACITY ON HATCH COVERS: 14
ON MAIN DECK: 28
STACKWEIGHT HC: 32.5 MT
MAIN DECK: 65 MT
REEFER PLUGS 42
INSURANCE
CERW
ACCOMMODATION
INSPECTION PLACE
DELIVERY PLACE PERU
PRICE USD 4.35 MILLION
REMARK USDA CERTIFICATE: 2014-11-15 (EXPIRY)
BOW THRUSTER
SHAFT GENERATOR
NO PERMANENT BALLAST
