REF606 KITANIHON ZOSEN, JAPAN 1983

NO. REF606
TYPE REEFER CARRIER
FLAG PANAMA
PORT OF REGISTRY PANAMA
BUILT built_in 1983
BUILT PLACE KITANIHON ZOSEN, JAPAN
CLASS BV
SS
DD
LOA 99.02 M
LR 91.41 M
LBP
BEAM 16.00 M
DEPTH 10.00 M
DRAFT 6.70 M
GT 3526 MT
NT 1678 MT
DWT 4192.42 MT
FLOOR SPACE CAPACITY
GEAR 6 DERRICKS×5.0 MT IN UP;
3×4.0 MT IN UP
ME AKASAKA DIESEL 6UEC 45/115H, 5400 HP
AE/GENERATOR YANMAR T260L-ST 1000HP, 720RPM×2 SETS
REF COMPRESSOR COMP. 1: BITZER HSN7471-75-4 OP 300CBM/HR-3500RPM 60KW;
COMP. 2: BITZER HSN7451-60-4 OP 230CBM/HR-3500RPM 60KW;
COMP. 3: MITSUBISHI MZ-93U 2STAGES 70KW;
COMP. 4: MITSUBISHI MZ-62L 2STAGES 40KW;
COMP. 5: MITSUBISHI MZ-12U 1STAGE 90KW;
COMP. 6: MITSUBISHI MZ-12U 1STAGE 90KW;
SPEED/CONSUMPTION
FUEL TYPE IFO 180=RMG 180 (FOR ME.);
MGO=DMB (FOR AE. AND ME. IN HARBOR SPEED)
HOLD NUMBER 3
HATCH NUMBER 3
HATCH SIZE 6.50 M×5.0 M
COMPARTMENT 9
DECKS
DECK AREA
DECK HEIGHT MIN. 2.20 M
CAPACITY (CBFT) 187535
CAPACITY (CBM) 5310
BUNKERS
TYPE OF THE VENT SYSTEM
VENT/AIR CIRCULATION
VENT
TEMPERATURE -23/+15℃
COOLING SYSTEM BRINE
COOLING SECTIONS 6
AGENT FREON R-22
PALLET
ACCOMMODATION 18
INSPECTION PLACE BANGKOK
DELIVERY PLACE BANGKOK
PRICE USD 1.5 MILLION
