REEFER, BUILT IN 1979, DWT 3534 MT

REEFER, BUILT IN 1979, DWT 3534 MT
2,000,000.00
Hakkında
REEFER, BUILT IN 1979, DWT 3534 MT
Reference Number
RF127453
Yıl
1979
DWT
3,534
Flag
ST KITTS
Ek Bilgiler
İlan Detayları
NAME REF111
TYPE REEFER
FLAG ST KITTS
BUILT built_in 1979
BUILT PLACE YSSELWERF, NETHERLAND
REBUILT built_in 1983
REBUILT PLACE Jsselwerf, NETHERLAND
CLASS RMRS L3 A3 REFS
SS LAST: 2008-02-09  NEXT: 2012-08-10
DD LAST: 2008-01-16  LAST: 2010-11-10
LOA 96.95 M
LBP 90.17 M
BEAM 13.75 M
DEPTH 7.7 M
DRAFT 5.12M (SUMMER)
GT/ NT 2768/1433 (INTERNATIONAL)
3049/2444 (PANAMA)
2886/2394 (SUEZ)
DWT 3534 MT (SUMMER)
FLOOR SPACE CAPACITY
GEAR CRANES NO.1 4.6MT  NO. 2  2.5MT
NO.3  5.0MT      NO. 4   4.4MT
OUTREACH 14M
ME DEUTZ RSBV6M540
2800BHP
AE/GENERATOR Deutz BA6 M 816
3×280KVA
SHAFT GENERATOR 450KVA
SPEED/CONSUMPTION MAX DISPLACEMENT: 10KNTS 6.5MT IFO+0.8MT MGO
ECONOMY LADEN: 7.0KNTS 4.0MT IFO+0.8MT MGO
FULL BALLAST: 10.5KNTS 6.5MT IFO+0.4MT MGO
ECONOMY BALLAST 8.0KNTS 4.0MT IFO+0.4MT MGO
FUEL TYPE
HOLD NUMBER 4
HATCH NUMBER 4
HATCH SIZE 9.42 X 8.86M
COMPARTMENT 8
DECKS 2
DECK AREA 1490 SQM
DECK HEIGHT MIN 2.11 M
CAPACITY (CBFT) 184121
CAPACITY (CBM) 5214
BUNKER CAPACITY 369T IFO 103T MGO
TYPE OF THE VENT SYSTEM
VENT VERT
TEMPERATURE -25+12 DC
COOLING SECTIONS 4 (EACH HOLD)
AIR CHANGE 75/HR
PALLET 1100 (SIZE: 1.2 X 1.0M)
GRATING RESISTENTS 2 MT (FORKLIFT INC CARGO ON PNEUMATIC TYRES)
BOW THRUSTER 185KW
INSPECTION PLACE THAILAND
DELIVERY PLACE BANGKOK
PRICE USD 2.0 MILLION, 30% DOWN PAYMENT AND BALANCE PAID IN 36 MONTHS WITHOUT INTEREST
REMARKS
