NO. REF366
TYPE REEFER
FLAG PANAMA
PORT OF REGISTRY PANAMA
BUILT YEAR 1989-1
BUILT PLACE FUKUOKA SHIPBUILDING Co, JAPAN
CLASS NK
SS 2013-11
DD 2013-11
LOA 117.40M
LBP 107.0M
BEAM 16.42M
DEPTH 9.95M
DRAFT SUMMER: 7.114 M
GT INTERNATIONAL: 4579 MT
PANAMA: 5090MT
SUEZ: 4767MT
NT INTERNATIONAL: 2156MT
PANAMA: 3593 MT
SUEZ: 3767 MT
DWT 5053MT
FLOOR SPACE CAPACITY 2184SQM
GEAR DERRICK 8 X 5MT / UP 3MT
ME MITSUBISHI-AKASAKA TYPE 8UEC37LA 5600 BHP 210 RPM
AE/GENERATOR A/E: 2×DAIHATSU 6DLB-22 900 PS×720RPM
GEN: 763 KVA
SPEED/CONSUMPTION MAIN ENGINE:
BALLAST/BANANA: ABT 16.5 KNOTS ON ABT 15 MTS/DAY IFO
DEEP LADEN: ABT 16.5 KNOTS ON ABT 15 MTS/DAY IFO (IFO 380 CST RMG-380)
D/G CONSUMPTION:
PORT-REEFER PLANT OFF: ABT 1.6 MTS/DAY (IFO 380 CST RMG-380)
PORT-REEFER PLANT ON: ABT 3 MTS/DAY (IFO 380 CST RMG-380)
FUEL TYPE IFO380
HOLD NUMBER 4
HATCH NUMBER 4
HATCH SIZE 5.50 x 5.00
COMPARTMENT 11 COMPARTMENTS
Hold No.1: A,B
Hold No.2-4: A,B,C
DECKS 3
DECK AREA
DECK HEIGHT MIN 2.20M
CAPACITY (CBFT) 197056
CAPACITY (CBM) 5580
COOLING SECTIONS 8 COOLING SECTIONS
GRATINGS WOODEN- MAX LOAD 5MT
(CARGO + FORKLIFT WITH 4 PNEUMATIC TYRES)
TYPE OF THE VENT SYSTEM
VENT
TEMPERATURE CARGO HOLDS TEMPS:
No 1.: -32℃ TO +32℃
No 2, 3, 4: -55℃ TO +32℃
INSPECTION PLACE BANGKOK
DELIVERY PLACE BANGKOK
PRICE USD 3.6 MILLION
REMARK ALL SPEEDS/CONSUMPTIONS BASIS CALM SEAS/MAX BEAUFORT 2.
VSL IS BURNING MDO WHEN NAVIGATING AND/OR MENOEUVERING AT REDUCED RPM, IN NARROW/SWALLOW/RESTRICTED WATERS (E.G. ENTERING/LEAVING PORT, TRANSITING CANALS AND SHIFTINGS AT T/S ANCHORAGES ETC.)
VESSEL LAID UP IN BANGKOK SINCE APRIL/2011
